Introduction
Electrical panel terminology gets thrown around loosely in procurement conversations — PCC, MCC, APFC, VFD — but each refers to a distinct panel type with a specific job in a facility’s power distribution. This guide breaks down the common types so you can specify and source the right one.
Power Control Centre (PCC)
The PCC is typically the main distribution point receiving incoming power (from a transformer or generator) and distributing it to downstream panels like MCCs and distribution boards.
Used for: Main incoming power distribution in industrial facilities, often the first panel after the transformer
Motor Control Centre (MCC)
An MCC houses the starters, contactors, and protection devices for multiple motors in a facility, centralizing motor control and protection in one enclosure.
Used for: Facilities with multiple motor loads — pumps, fans, compressors — where centralized control and protection simplifies operation and maintenance
Automatic Power Factor Correction (APFC) Panel
APFC panels automatically switch capacitor banks in and out of a circuit to maintain the power factor close to unity, reducing reactive power penalties on the electricity bill.
Used for: Facilities with inductive loads (motors, transformers) where power factor penalties are a cost concern — common in most medium-to-large industrial connections
Variable Frequency Drive (VFD) Panel
Houses VFDs that control motor speed by varying the frequency and voltage supplied, rather than running motors at fixed speed.
Used for: Applications needing variable motor speed — pumps and fans with varying load/flow requirements, where VFDs also offer significant energy savings over fixed-speed operation with throttling
Distribution Panels / Distribution Boards (DBs)
Smaller panels that distribute power from an upstream source to individual circuits — lighting, small equipment, plug loads.
Used for: Final-stage power distribution to end loads throughout a facility
Quick Comparison
| Panel type | Main function | Typical location in system |
| PCC | Main incoming power distribution | First panel after transformer/generator |
| MCC | Centralized motor control & protection | Downstream of PCC, feeding multiple motors |
| APFC | Power factor correction | Parallel to main distribution, reduces reactive power penalty |
| VFD Panel | Variable motor speed control | Feeding specific variable-speed motor loads |
| Distribution Panel/DB | Final circuit distribution | End-stage, feeding lighting/small loads |
What to Specify When Sourcing a Panel
- Rated current and voltage matched to your facility’s load requirements
- IP rating appropriate to the installation environment (indoor, outdoor, dusty, wet)
- Compliance standard — IS 8623 (India) or IEC 61439 depending on project requirements
- Busbar material and rating — copper vs. aluminum, and current-carrying capacity
- Type test certification from the manufacturer for the specific panel design
Typical Panel Sizing and Rating Considerations
A few specifications determine most of a panel’s cost and suitability:
- Rated current (Amps) and short-circuit withstand rating — sized to your facility’s actual and projected future load, not just current demand
- Enclosure IP rating — IP20–IP42 for clean indoor environments, IP54–IP65 for dusty, wet, or outdoor installations
- Busbar sizing and material — copper offers better conductivity but costs more than aluminum; sizing affects both cost and the panel’s physical dimensions
- Number of feeders/outgoing circuits — directly affects panel size and compartmentalization requirements
Common Mistakes When Sourcing Electrical Panels
- Sizing only for current load, not future expansion — retrofitting a panel later is far more disruptive and costly than specifying reasonable spare capacity upfront
- Overlooking site environmental conditions — an indoor-rated panel installed in a dusty or humid environment will have a shortened service life
- Not confirming type-test certification when required — some projects specifically require type-tested panels per IEC 61439; verify this is included, not just assumed
- Underestimating installation and commissioning time — larger panels, especially MCCs with multiple motor starters, need adequate time for factory testing and site commissioning, not just manufacturing lead time
Frequently Asked Questions
Do I need a separate APFC panel, or can it be integrated into the PCC?
Both approaches are common — integration depends on facility size, load profile, and whether capacitor banks are centralized or distributed; a design engineer can advise based on your specific load analysis.
What’s the difference between type-tested and non-type-tested panels?
Type-tested panels have been verified by an independent lab against a specific design standard (e.g., IEC 61439); this is increasingly a specification requirement for safety and reliability assurance.
Can one panel combine MCC and PCC functions?
For smaller facilities, combined panels are common; for larger industrial setups, separating PCC and MCC functions is standard practice for easier maintenance and fault isolation.
